Product Overview
Customized Automotive Aluminum Radiator Header Plates
The Customized Car Aluminum Radiator Header Plate (a.k.a. top plate / tank plate) locks the cooling tubes and seals the plastic tank with a vulcanized gasket. Every plate is CNC punch-formed from 3-layer clad aluminum to guarantee leak-free service up to 0.9 bar and 150 °C continuous.
Material Options
Customized Automotive Aluminum Radiator Header Plates
1. Standard: 4343/3003/7072 clad ( High braze yield, self-sacrificing 7072 | 1.5 mm ±0.05 mm )
2. Lightweight: 3003-H18 bare ( −12 % weight, lower cost | 1.4 mm ±0.05 mm )
Precision & Features
Customized Automotive Aluminum Radiator Header Plates
1. Hole position ±0.05 mm (Cpk ≥1.67) – zero tube pullback after brazing
2. Burr ≤0.03 mm, Ra ≤0.6 µm – ready for vacuum or CAB brazing
3. Ø16-32 mm holes, pitch 6.5-8.0 mm, 1-3 rows, width 260-720 mm
4. Optional coined O-ring groove 0.4 mm deep, EPDM-compatible
5. Logo / part-number laser etched before anodizing (no extra cost ≥500 pcs)
6. Clear or black anodizing 8-12 μm, 500 h salt-spray pass
Technical Specifications
Customized Automotive Aluminum Radiator Header Plates
1. Alloy: 4343/3003/7072 or 3003-H18
2. Thickness: 1.4 / 1.5 / 1.8 / 2.0 mm
3. Width: 260-720 mm
4. Rows: 1-3
5. Hole dia: Ø16-32 mm
6. Pitch: 6.5-8.0 mm
7. Brazing: Vacuum / CAB 605-615 °C
8. Finish: Mill / Clear anodized / Black anodized
Applications
Customized Automotive Aluminum Radiator Header Plates
1. Universal Fit: Compatible with all car brands and models when custom fabricating radiator assemblies
2. Common Applications:
– Japanese: Toyota Camry/Corolla, Honda Accord/Civic, Nissan Altima
– American: Ford F-150/Mustang, Chevrolet Silverado, Dodge RAM
– European: VW Passat, BMW 3/5 Series, Mercedes C/E-Class, Audi A4
– Korean: Hyundai Sonata, Kia Optima
Automotive Aluminum Radiator Header Plates
Custom car aluminum radiator header plates 4343/3003/7072, ±0.05 mm tolerance, 1.5 mm, 1-3 rows, anodized or mill finish. For custom specifications or technical consultations, please provide your radiator core drawings or sample plates for rapid quotation. Free Samples. Low MOQ. Factory-Direct Pricing. Affordable Price. Request a Quote Today.
