This machine can automatically insert the fins (which are finished by the fin-forming machine) into flat tubes. It consists of a tube warehouse, fin transmission, flaring, fin inserting devices, etc. This machine, together with the fin-forming machine, automatically finishes the fin-inserting process. The length of the flat tube decides the quantity of fin inserting.
The machine consists of a tube warehouse, fin transmission, flaring and fin inserting devices, etc.
This machine and the fin-forming machine automatically finish the fin-inserting process. The length of the flat tube decides the quantities every time a fin is inserted.
| Work Piece specification | Design per specification |
| Production capacity | Calculate per length |
| Drive mode | Servo+Pneumamtic |
| Overall dimension | 4200*1800*1800mm |
| Weight | 2.2 T |
| Product Origin | CHINA |
|---|---|
| Brand Name | DaG MC |
| Model Number | DG-FI |
| MOQ | 1 |
| Lead Time | 60 day |
| Payment | 30% DEPOSIT,70% BEFORE DELIVERY |
| Packaging Details | Wooden boxes that meet international export standards |
| Supply Ability | 10sets/month |
DAG is your first choice if you want to set up a radiator factory at your location. We will provide you with the best services.
